OBJ Importer

The OBJ importer supports convex polygonal faces with up to 128 vertices. Geometric, normal, and texture vertices are loaded.

In addition, untrimmed B-SPLINE “curv” and “surf” entities are supported.

Material properties are read from the OBJ file or from a referenced MTL file if it is present in the workspace. Material properties are approximated to match a corresponding material definition in 3DS format.

Everything else in the OBJ file is ignored by 3Dskope.

If you find issues with the OBJ importer you may E-mail us copies of your OBJ and MTL files for investigation. Please ZIP the files and also include a screenshot to show how the file should be displayed properly.
